Various Durable 360 Rotating Pillar Column Mounted Rotating Jib Crane
Product Category:
Product Description:
Mingdao company has six functional departments, including R&D department, sales&after-sales department, materials supply department, production department, QC department and finance department. There are 16 workshops including electrical, riveting, forging, assembly, heat treatment, machining and maintenance.

Hotline:
The QB model series floor mounted jib cranes are designed and constructed for industrial use . The jib crane boom is fabricated
out of a steel "S" or "W" shaped I beam and have removable end stops. A machined lower roller carriage is housed in the jib
crane head section which feature heavy steel side plates.The lower roller carriage is mounted on adjustable tension bolts to
allow 360 dgree field adjustments. The support column for the jib crane is constructed out of steel pipe with a heavy base plate and
reinforcing gussets. This type jib crane can be used both indoor and outdoor places.
It can be operated under three-dimensional environment by pendent push button or remote controller. Compared to other
lifting device, it is superior especially in the case of short-distance and concentrated lifting.
Technical parameters,
Type |
BZ0.25 |
BZ0.5 |
BZ1 |
BZ2 |
BZ3 |
BZ5 |
BZ8 |
BZ10 |
|
Lift Capacity (t) |
0.25 |
0.5 |
1 |
2 |
3 |
5 |
8 |
10 |
|
Max. Lift Height(m) |
3 |
3 |
3 |
3 |
4 |
4 |
6 |
8 |
|
Slew Angle(0) |
360 |
360 |
360 |
360 |
360 |
360 |
360 |
360 |
|
Lift Speed (m/min) |
Normal |
4;10;8 |
5;10;8 |
8 |
8 |
8 |
8 |
8 |
8 |
Slow |
1;2.5;0.8 |
1.25;2.5 |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
|
Level Travel Speed (m/min) |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
|
Slewing Speed (r/min) |
0.7 |
0.7 |
0.7 |
0.7 |
0.6 |
0.6 |
0.6 |
0.6 |
|
Lift mechanism |
wire rope electric hoist or chain electric hoist |
||||||||
Power supply |
380-420V/3phase/50hz or customized |
||||||||
Control mode |
Pendent push button control or remote control |
||||||||
Above parameter just for your reference,jib crane can be customized design Max.20t according to your demands. |
Product details:
Package & Delivery:
Our service:
Pre-Sales Service
1.Inquiry and consulting support* View our Factory
2.Design drawing of CAD
During production period
1. Strict quality control system, supervision the work to ensure the best crane for you.
2. Strict production line, make sure manufacture the goods on time.
3. Send real time production procedure video and pictures for customers
4. Best cooperation forwarder provide the soonest and reliable service for our goods.
After-Sales Service
1.Training how to install the machine, training how to use the machine. Engineers available to service machinery overseas.
2. Installation service
3. Online support* Radio support
4. Telephone support. Engineering service
5. Will provide all technical documents by U flash desk when delivery and soft copy (Installation manual, instruction, electrical drawing, 3D drawing etc)
Mingdao Cranes is the leading manufacturer and service provider of lifting and Materials handling products. Dedicated to the research and development of lifting and Materials handling technologies, Mingdao Cranes can provide customers a wide range of lifting products with compact design, low headroom, good safety, high performance and efficient operation. We are committed to help our customers cut down factory investment, improve production efficiency, reduce daily maintenance, economize energy consumption and achieve best Return on Investment.
Welcome contact with us with the following specifications:
1.Lift capacity?
2.Lift height?
3.The span?
4.Local power supply?
5.Crane travel length?
6.What materials will the crane lift?
